Product Information

Elegant tube on tube design consisting of a tight array of slim tubes makes the Arno range an easy choice for any bathroom or kitchen.

Strictly controlled independent laboratory testing ensures that the Henrad Arno Towel Rail Range radiators are guaranteed to perform to a maximum working pressure of 87 psi (6 bar), and conform to BS EN 442, the European Standard for radiators.

Every radiator comes wrapped in robust, practical packaging that will keep the product pristine, right through to handover. Protective through storage and transit, the new packaging design also allows for installation prior to removal.

Technical Information

Henrad combines the most sophisticated production resources in Europe with substantial investment in testing and verification of performance data, which has helped us create high output radiators delivering heating performance that exceed expectation.

We also want to exceed expectations when it comes to customer service, and our experts are on hand to support and understand your technical specification needs.

All table figures are based on Btu/hr ∆t50 °C

product-icon

Arno Single

Height mm Length mm Henrad Code UIN Colour Heat Emissions Watts Heat Emissions Btu/hr Price excl. VAT
450 792 417902450 417902451 389 1327 £210.50
500 792 417902500 417902501 431 1471 £236.52
600 792 417902600 417902601 517 1764 £262.54
750 792 417902750 417902751 645 2201 £288.55
450 1088 411002450 411002451 615 2098 £223.51
500 1088 411002500 411002501 675 2303 £249.53
600 1088 411002600 411002601 794 2709 £275.55
750 1088 411002750 411002751 972 3316 £301.56
450 1680 411602450 411602451 900 3071 £301.56
500 1680 411602500 411602501 986 3364 £328.76
600 1680 411602600 411602601 1158 3951 £354.78
750 1680 411602750 411602751 1416 4831 £380.80
450 1976 411902450 411902451 1002 3419 £328.76
500 1976 411902500 411902501 1099 3750 £354.78
600 1976 411902600 411902601 1294 4415 £380.80
750 1976 411902750 411902751 1586 5411 £406.81

Arno Double

Height mm Length mm Henrad Code UIN Colour Heat Emissions Watts Heat Emissions Btu/hr Price excl. VAT
450 792 427902450 427902451 552 1883 £275.55
500 792 427902500 427902501 616 2102 £301.56
600 792 427902600 427902601 748 2552 £328.76
750 792 427902750 427902751 947 3231 £354.78
450 1088 421002450 421002451 868 2962 £301.56
500 1088 421002500 421002501 963 3286 £328.76
600 1088 421002600 421002601 1154 3937 £354.78
750 1088 421002750 421002751 1441 4917 £380.80
450 1680 421602450 421602451 1268 4326 £393.81
500 1680 421602500 421602501 1402 4784 £419.82
600 1680 421602600 421602601 1670 5698 £445.84
750 1680 421602750 421602751 2073 7073 £473.04
450 1976 421902450 421902451 1427 4869 £432.83
500 1976 421902500 421902501 1576 5377 £460.03
600 1976 421902600 421902601 1874 6394 £486.05
750 1976 421902750 421902751 2321 7919 £512.07

Arno Curved

Height mm Length mm Henrad Code UIN Colour Heat Emissions Watts Heat Emissions Btu/hr Price excl. VAT
792 496 447902496 447902497 431 1471 £249.53
792 595 447902595 447902596 517 1764 £262.54
1088 496 441002496 441002497 675 2303 £275.55
1088 595 441002595 441002596 794 2709 £288.55
1680 496 441602496 441602497 986 3364 £328.76
1680 595 441602595 441602596 1158 3951 £354.78
1976 496 441902496 441902497 1099 3750 £354.78
1976 595 441902595 441902596 1294 4415 £393.81
Btu/hr @ ΔT50°C
